DESCRIPTION

Basic Info

Model NO.	1209G
Functional Layer	Laminating
Packaging	Carton+Pallet
Paper Core	1 Inch/2.25 Inches/3 Inches
Width	300 ~ 1800 mm
Length	300 ~ 3000 M
Thickness	18mic~35mic
Surface	Gloss or Matt
Transport Package	Carton Box(+Pallet If Needed)
Specification	SGS RoHS
Trademark	FSEKO
Origin	China
HS Code	392020
Production Capacity	4500 Tons/Year

Product Description

*Material

Surface layer: BOPP
Glue layer: EVA adhesive



*Specification

Gloss

SPECIFICATION				18mic	21mic	24mic	24mic	27mic	30mic
				GLOSS	GLOSS	GLOSS	GLOSS	GLOSS	GLOSS
THICKNESS (mic)		BASE		12	12	12	15	15	18
		ADHESIVE		6	9	12	9	12	12
		TOTAL		18	21	24	24	27	30
WEIGHT		m2/kg		60.4	51.6	45.045	45.45	40.11	36.15
		kg/m2		0.01656	0.01938	0.0222	0.022	0.02493	0.02766
WIDTH(mm)		300mm-1800mm
LENGTH(m)		200m-3000m
PARER CORE		25mm(1inch),58mm(2.25inches),76mm(3inches)
BONDING		LESS THAN 2

Matt

SPECIFICATION				24mic	27mic	30mic
				MATT	MATT	MATT
THICKNESS (mic)		BASE		15	15	18
		ADHESIVE		9	12	12
		TOTAL		24	27	30
WEIGHT		m2/kg		46.3	41	37
		kg/m2		0.0216	0.0244	0.0271
WIDTH(mm)		300mm-1800mm
LENGTH(m)		200m-3000m
PARER CORE		25mm(1inch),58mm(2.25inches),76mm(3inches)
BONDING		LESS THAN 2

*Process parameter:

	normal	special
Temperature	85 ~ 100ºC	100 ~ 110 ºC
Roll Pressure	8 ~ 15Mpa	16 ~ 25 Mpa
Speed	5 ~ 30 M/min	5 ~10 M/min
Lamination Equipment	dry and wet laminator
Remarks	Special laminations refer to those with thick ink, dark color, much moisture and large size paper



*Directions for using BOPP thermal laminating film:

Normal process temperature is 90c-105c, roller pressure and temperature vary with different types of paper, ink and machines.
When using the film for the first time or do other treatment, try a small volume before mass laminating.
Make sure the ink is dry before laminating. It will delaminate when the paper contains too much moisture and powder.
Make sure put the material in a low-temperature, dry place.

*Packaging:

Standard export package with carton+pallet.
